Nissan NV400 (M) 07/2014- 07/2020*
Nissan NV400 (M) 07/2020 - 12/2021*
Opel
Opel Movano B (X62) 06/2013 - 09/2019*
Renault
Renault Capture (R) 06/2013 - 12/2019*
Renault Clio IV (X98) 11/2012 - 06/2016**
Renault Clio IV (X98) 06/2016 - 12/2020**
Renault Grand Scenic 04/2012 - 09/2016****
Renault Master III (M) 09/2014 - 09/2019*
Renault Megane III (Z/BZ) 04/2012 - 12/2013
Renault Megane III (Z/BZ) 01/2014 - 07/2016***
Renault Scenic (JZ) 02/2012 - 09/2016****
Renault Trafic III (J/JL) 09/2014 - 07/2019****/*****
Renault Trafic III (J/JL) 09/2019 - 03/2022**/****/*****
Renault Twingo II (N) 01/2012 - 07/2014****
Renault Twingo III (AH) 09/2014 - 04/2019*****
Renault Wind (N) 08/2010 - 08/2013****
Following signals are provided:
Reimported vehicles or vehicles with different software may be incompatible in functions.
red: +12V ignition clamp 15
orange: +12V illumination clamp 58
purple/white: +12V reverse signal
pink: speed pulse signal
green: GND park brake signal
load capacity total outputs: 100 mA max.
SWC
*vehicles without OEM Sat Nav
*vehicles without 1-DIN OEM HU black with frontAUX/USB 2 x rotary knob
**vehicles with R-Link OEM Sat Nav OEM Sat Nav display with silverbox without front AUX/USB
***vehicles with Radio+ Continental OEM HU
****vehicles with 1-DIN OEM HU silver with front USB
****vehicles with 1-DIN OEM HU black with front USB > item: 42srn009
*****vehicles with R-Link OEM HU
